Product Details
| 製品名: | 合金鋼の版 | 標準: | AISI、ASTM、BS、DIN、JIS |
|---|---|---|---|
| 適用: | 船の版 | 技術: | 冷間圧延される/つや出し |
| ハイライト |
圧力容器の版,船の鋼板 |
||
Product Description
Q235 Q345 B C D Eは6 - 80mm冷間圧延しましたり/つや出しの合金鋼の版の厚さ
Q345B/C/D/E
1）標準:GB
2）厚さ:6-80mm
3）幅:1600-3200mm
4）長さ:6000-14000mm
5））良質の低価格
化学要素（WT %）
| C | Si | Mn | P | S | V | Nb | Al | チタニウム | |
| Q345A | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.045 | ≤0.045 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345B | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.040 | ≤0.040 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345C | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.035 | ≤0.035 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345D | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.030 | ≤0.030 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345E | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.025 | ≤0.025 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
機械Properities
| 厚さ | 温度（°c）をテストして下さい | 延長（%） | 耐力（Mpa） | 抗張strenth （Mpa） | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
私達のプロダクト
| プロダクト シリーズ | 管理の標準 | 等級 | クラス | 厚さ（mm） |
配達 国家 |
| 低合金の構造スチール | GB/T 1591-2008GB/T 3274-2007 | Q345 | A、B | 6~150 | AR |
| C、D | 6~150 | CR | |||
| E | 6~150 | TMCP | |||
| Q390 | A、B、C、D、E | 6~150 | CR | ||
| Q420 | 6~150 | TMCP | |||
| Q500 | 6~100 | TMCP | |||
| Q550 | 6~100 | ||||
| Q620 | 6~80 | ||||
| Q690 | 6~80 | ||||
| GB/T 28410-2012 | Q235FT | B、C、D、E | 5~150 | ARのCR | |
| Q275FT | C、D、E、F | 5~150 | ARのCR | ||
| Q345FT | C、D、E、F | 5~150 | ARのCR | ||
| Q420FT | C、D、E、F | 5~150 | ARのCR | ||
| Q460FT | C、D、E、F | 5~150 | ARのCR | ||
| ENの10025-4:2004 | S275M/ML | - | 6~60 | TMCP | |
| S355M/ML | |||||
| S420M/ML | |||||
| S460M/ML | |||||
| JIS G3106:2008年 |
SM400 SM490 |
A、B、C | 6~150 | AR | |
| A、B、C | 6~150 | CR | |||
| YA、YB | |||||
| SM520 | B、C | 6~80 | TMCP | ||
| SM570 | 6~80 | ||||
| ASTM A572/A572M-12 | Gr42 | - | 6~150 | AR | |
| Gr50 | - | 6~100 | CR | ||
| Gr55 | - | 6~100 | |||
| Gr60 | - | 6~80 |
TMCP |
Product Highlights
Q235 Q345 B C D Eは6 - 80mm冷間圧延しましたり/つや出しの合金鋼の版の厚さ Q345B/C/D/E 1）標準:GB2）厚さ:6-80mm3）幅:1600-3200mm4）長さ:6000-14000mm5））良質の低価格 化学要素（WT %） C Si Mn P S V Nb Al チタニウム Q345A ≤0.20 ≤0.55 1.00-1.60 ≤0.045 ≤0.045 0.02-0.15 0.015-0.060 - 0.02-0.20 Q345B ≤0.20 ≤0.55 1.00-1.60 ≤0.040 ≤0.040 0.02-0.15 0.015-0.060 - ...
