熱するパイプラインのためのASTM A53 APIの炭素鋼の継ぎ目が無い管GB5310
Product Details
| 製品名: | ボイラー管 | 標準: | 中国GB5310 |
|---|---|---|---|
| 適用: | 暖房パイプライン、容器、石炭セービング装置過熱装置および再加熱装置 | 主要な鋼管の等級: | 20G、25MnGの、15MoGの、15CrMoGの、12Cr2MoGの、12Cr1MoVG |
| ハイライト |
APIの炭素鋼の継ぎ目が無い管,ASTM A53の継ぎ目が無い管,GB5310炭素鋼の継ぎ目が無い管 |
||
Product Description
ASMEの標準的な炭素鋼の継ぎ目が無い管/管ASTM A53 API 5L GrB A106 GrB
プロダクト細部
| プロダクト | 冷たい引く精密継ぎ目が無い鋼管の製造業者 |
| 材料 | 炭素鋼および合金鋼 |
| 標準 | JIS3445、DIN2391、EN10305-1、GB/T3639 |
| 等級 |
STKM11A、STKM12B、STKM13A、STK400、E235、ST37.4、ST35.8、ST44、ST45、E255、 CK45、S45C、AISI4130、AISI4135、AISI4140 |
| 証明書 | ISO9001 |
| 技術 | 冷間圧延される及び冷たい-引かれる |
| 適用 |
車、自動車、オートバイ、ガスばね、油圧機械類で広く利用された、 建設機械および冷凍の企業。 |
| パッケージ | プラスチック編まれた袋が付いている束の覆い |
| 貿易言葉 | T/T、L/C |
| 供給の状態 | BK、BKS、BKW、NBK、GBK
|
| 受渡し時間 | 時間 |
化学Compositon及び機械Propertise:
| 標準 | 等級 | 化学成分（%） | ||||||
| C | Mn | Si | V | Cr | Mo | P.S | ||
| GB5310 | 20G | 0.17~0.24 | 035~0.65 | 0.17~0.37 | / | / | / | ≤ 0.030 |
| 25MnG | 0.22~0.30 | 0.70~1.00 | 0.17~0.37 | / | / | / | ≤ 0.030 | |
| 15MoG | 0.12~0.20 | 0.40~0.80 | 0.17~0.37 | / | / | 0.25~0.35 | ≤ 0.030 | |
| 15CrMoG | 0.12~0.18 | 0.40~0.70 | 0.17~0.37 | / | 0.80~1.10 | 0.40~0.55 | ≤ 0.030 | |
| 12Cr2MoG | 0.08~0.15 | 0.40~0.70 | ≤ 0.50 | / | 2.00~2.50 | 0.90~1.20 | ≤ 0.030 | |
| 12Cr1MoVG | 0.08~0.15 | 0.40~0.70 | 0.17~0.37 | 0.15~0.30 | 0.90~1.20 | 0.25~0.35 | ≤ 0.030 | |
| 機械Propertise | 引張強さ（Mpa） | 降伏強さ（Mpa） | 延長（%） | |||||
| 20G | 410~550 | ≥ 245 | ≥ 24 | |||||
| 25MnG | ≥ 415 | ≥ 240 | ≥ 22 | |||||
| 15MoG | 450~600 | ≥ 270 | ≥ 22 | |||||
| 15CrMoG | 440~640 | ≥ 235 | ≥ 21 | |||||
| 12Cr2MoG | 450~600 | ≥ 280 | ≥ 20 | |||||
| 12Cr1MoVG | 470~640 | ≥ 255 | ≥ 21 | |||||
Product Highlights
ASMEの標準的な炭素鋼の継ぎ目が無い管/管ASTM A53 API 5L GrB A106 GrB プロダクト細部 プロダクト 冷たい引く精密継ぎ目が無い鋼管の製造業者 材料 炭素鋼および合金鋼 標準 JIS3445、DIN2391、EN10305-1、GB/T3639 等級 STKM11A、STKM12B、STKM13A、STK400、E235、ST37.4、ST35.8、ST44、ST45、E255、 CK45、S45C、AISI4130、AISI4135、AISI4140 証明書 ISO9001 技術 冷間圧延される及び冷たい-引かれる 適用 車、自動車、オートバイ、ガスばね、油圧機械...
高周波溶接のカスタマイズされた石炭は蒸気ボイラの部品を積み重ねるエコノマイザのコイルを始動させた
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
エコノマイザの熱伝達のための高周波溶接のボイラー螺線形のひれ付き管
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
動力火車の実用的な植物のための熱交換器Hのタイプ ボイラー部品の管
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
延長暖房の産業発電所のボイラーのための表面のボイラーひれ付き管
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
